Product Details
Opening from 0 to 4-1/4 in., this clamp delivers 6,200 lbs. of clamping force with a 3-1/4 in. throat depth. Purpose-built for steel fabrication and welding environments, the copper-plated spindle resists weld spatter fusion that seizes standard spindles after repeated exposure. The high-visibility safety orange finish makes this clamp immediately identifiable in busy fabrication shops, overhead crane setups, and multi-station welding cells. Drop forged steel construction delivers frame strength that handles the thermal stresses of welding-adjacent clamping without distortion. The hardened acme thread spindle maintains smooth operation even after extended heat exposure, and the swivel pad conforms to workpiece contours. When welding fixtures demand clamps that stay visible, stay functional, and resist spatter damage, the Spark-Duty Hi-Vis is the professional-grade answer.
Features
- Opens 0 in. - 4-1/4 in. for versatile fixturing on plate, pipe, and structural steel
- 3-1/4 in. throat depth positions clamping pressure past flanges and edges
- 6,200 lbs. clamping force locks workpieces firmly during tack and full welds
- Built from Drop Forged Steel, rated at 6,200 lbs. across the complete 4-1/4 in. opening
- Spindle applies 6,200 lbs. evenly across 3-1/4 in. throat without deflection or drift (WL9-20483)
- Swivel contact pad reduces the risk of workpiece slippage under force — up to 0 in. - 4-1/4 in. — 3-1/4 in. throat depth
- 3.4 lbs. —light enough for frequent repositioning, strong enough for production
Specifications
- SKUWL9-20483
- Material TypeDrop Forged Steel
- Model Number404CS
- Product TypeTools & Equipment
- Spindle Diameter3/4 in.
- Throat Depth3-1/4 in.
- UPC019907204831
